2-18
Chapter 2. PARA BANK SETTINGS
 Output bank (OUt)
Display Output number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
CO-0 1 3.
Output range Current output
0: 4 to 20 mA 1: 0 to 20 mA
Continuous voltage output
0: 1 to 5 V 1: 0 to 5 V 2: 0 to 10 V
0
CO-02 3.
Output type 0: 0 % fixed 1: MV
2: Heat-side MV (for heat/cool control)
3: Cool-side MV (for heat/cool control)
4: PV (loop) 5: SP 6: Deviation (PV-SP)
7: PV (input channel) Others
1 Setting range is 0 to 3071, but 8
to 2047 are undefined.
For more details on the 2048 to
3071 range, see the: Standard
numerical codes (P.4-3).
CO-03 3.
Loop/channel definition 0: Invalid 1: Loop 1/channel 1
2: Loop 2/channel 2
1 Setting range is 0 to 99.
CO-04 3.
Output decimal point
position
0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
1
CO-05 3.
Output scaling low limit -19999 to +32000 U 0.0 The decimal point position is
determined by the decimal point
for the output.
CO-06 3.
Output scaling high limit 100.0
CO-07 3.
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
0
CO-08 3.
Power voltage correction
selection
0: Disabled 1: Corrected by AC1 input
2: Corrected by AC2 input
0 Selectable on the SDC45R/46R
only.
CO-0 1 4.
Output range Same as output 3 0 Same as output 3
CO-02 4.
Output type 0
CO-03 4.
Loop/channel definition 1
CO-04 4.
Output decimal point position 1
CO-05 4.
Output scaling low limit 0.0
CO-06 4.
Output scaling high limit 100.0
CO-07 4.
Linearization table group definition 0
CO-08 4.
Power voltage correction selection 0
CO-0 1 5.
Output range Same as output 3 0 Same as output 3
CO-02 5.
Output type 0
CO-03 5.
Loop/channel definition 1
CO-04 5.
Output decimal point position 1
CO-05 5.
Output scaling low limit 0.0
CO-06 5.
Output scaling high limit 100.0
CO-07 5.
Linearization table group definition 0
CO-08 5.
Power voltage correction selection 0
CO-0 1 6.
Output range Same as output 3 0 Same as output 3
CO-02 6.
Output type 0
CO-03 6.
Loop/channel definition 1
CO-04 6.
Output decimal point position 1
CO-05 6.
Output scaling low limit 0.0
CO-06 6.
Output scaling high limit 100.0
CO-07 6.
Linearization table group definition 0
CO-08 6.
Power voltage correction selection 0
CO-0 1 7.
Output range Same as output 3 0 Same as output 3
CO-02 7.
Output type 0
CO-03 7.
Loop/channel definition 1
CO-04 7.
Output decimal point position 1
CO-05 7.
Output scaling low limit 0.0
CO-06 7.
Output scaling high limit 100.0
CO-07 7.
Linearization table group definition 0
CO-08 7.
Power voltage correction selection 0
TPO.0 1 1.
Output type 0: OFF 1: Loop 1 MV
2:
Loop 1 Heat-side MV (for heat/cool control)
3: Loop 1 Cool-side MV (for heat/cool control)
4: Loop 2 MV
5:
Loop 2 Heat-side MV (for heat/cool control)
6:
Loop 2 Cool-side MV (for heat/cool control)
13 : Position proportional output 1 output
for closing
14 : Position proportional output 1 output
for opening
Others
0 Setting range is 0 to 2047, but 7
to 1023 are undefined.
For more details on the 1024 to
2047 range, see the Standard
bit codes (P.4-1).
