Azbil SDC46 User Manual

2-37
Chapter 2. PARA BANK SETTINGS
 Display/key bank (hMi)
Display
MS display
Status number/
F key number/
UF LED number
(auxiliary display)
Item Meaning
of
Auxiliary
display
Settings and descriptions Initial
value
User
setting
Remarks
MS-0 1 1.
Multi-status (MS) display,
Status
Top
priority
1024 to 2047 1568 Setting range is 1024 to 2047.
For details, see the Standard
bit codes (P.4-1).
MS-02 1.
Multi-status (MS) display,
Condition
Top
priority
0: Lit 1: Slow flashing
2: Double flashes 3: Fast flashing
4: Left to right 5: Right to left
6:
Reciprocating between left and right
7: Deviation OK (loop 1)
8: Deviation OK (loop 2)
11: Deviation graph (loop 1)
12: Deviation graph (loop 2)
15: MV graph (loop 1)
16: MV graph (loop 2)
19: Heat-side MV graph (loop 1)
20: Heat-side MV graph (loop 2)
23: Cool-side MV graph (loop 1)
24: Cool-side MV graph (loop 2)
29: DI/DO monitor (columns C+F)
30: DI/DO monitor (column D)
31: DI/DO monitor (column E)
32: Event status monitoring
Others
1 Setting range is 0 to 3071.
MS-03 1.
Multi-status (MS) display,
Decimal point position
Top
priority
0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
1
MS-04 1.
Multi-status (MS) display,
scaling low limit
Top
priority
-19999 to +32000 U 0.0 The decimal point position is
determined by the decimal
point position for the MS
display.
MS-05 1.
Multi-status (MS) display,
scaling high limit
Top
priority
100.0
MS-0 1 2.
Multi-status (MS) display,
Status
Second
priority
Same as multi-status (MS) display,
Status (top priority)
1792 Same as multi-status (MS) dis-
play, Status (top priority)
MS-02 2.
Multi-status (MS) display,
Condition
Second
priority
6
MS-03 2.
Multi-status (MS) display,
Decimal point position
Second
priority
1
MS-04 2.
Multi-status (MS) display,
Second scaling low limit
Second
priority
0.0
MS-05 2.
Multi-status (MS) display,
scaling high limit
Second
priority
100.0
MS-0 1 3.
Multi-status (MS) display,
Status
Third
priority
Same as multi-status (MS) display,
Status (top priority)
1025 Same as multi-status (MS) dis-
play, Status (top priority)
MS-02 3.
Multi-status (MS) display,
Condition
Third
priority
15
MS-03 3.
Multi-status (MS) display,
Decimal point position
Third
priority
1
MS-04 3.
Multi-status (MS) display,
scaling low limit
Third
priority
0.0
MS-05 3.
Multi-status (MS) display,
scaling high limit
Third
priority
100.0
FK-0 1 1.
F key basic registration rsp/lsp
key
0: No registration 1: Item setting
2: RUN/READY selection
4: AT Start/Stop selection
5: LSP/RSP selection
6: Backup/through output selection
7: User-defined bit 1 selection
8: User-defined bit 2 selection
9: User-defined bit 3 selection
10: User-defined bit 4 selection
11: User-defined bit 5 selection
12: User-defined bit 6 selection
13: User-defined bit 7 selection
14: User-defined bit 8 selection
5 Setting range is 0 to 255
FK-02 1.
F key assignment item 1 rsp/lsp
key
00000: Invalid
Communication address (for RAM) is
set by hexadecimal value.
00000 Setting range is 00000 to
0FFFF
FK-03 1.
F key assignment item 2 rsp/lsp
key
FK-04 1.
F key assignment item 3 rsp/lsp
key
