Azbil SDC46 - Position Proportional Bank ( PP ); CT Input Bank ( CT ); AC Input Bank ( Ac )

2-20
Chapter 2. PARA BANK SETTINGS
 Position proportional bank (PP)
Display Loop number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
PP-0 1 1.
Output type 0: Position proportional control stop
1: MV of loop 1
2: Heat MV of loop 1
3: Cool MV of loop 1
4: MV of loop 2
5: Heat MV of loop 2
6: Cool MV of loop 2
2048 to 3071: According to the Standard
numerical codes list.
0 Setting range is 0 to 3071.
PP-02 1.
Control type 0: MFB control + estimated position control
1: MFB control + close at burnout
2: Estimated position control
3:
Estimated position control+positioning
at power supply ON
-
PP-03 1.
Dead zone 0.5 to 25.0 % -
PP-04 1.
Motor long life mode 0: Aiming at controllability
1: Aiming at life
-
PP-05 1.
Motor auto adjust 0: Stop 1: Start -
PP-06 1.
Input with motor fully closed 0 to 8000 -
PP-07 1.
Input with motor fully open 0 to 8000 -
PP-08 1.
Motor full close-full open time 5.0 to 240.0 s -
PP-09 1.
Loop 1: Loop 1 2: Loop 2 -
PP- 10 1.
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
-
 CT input bank (CT)
Display CT input number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
CT-0 1 1.
CT operation type 0: Continuous current measurement
1: Heater burnout detection of OUT1
2: Heater burnout detection of OUT2
3: Heater burnout detection of OUT3
4: Heater burnout detection of OUT4
5: Heater burnout detection of OUT5
0
CT-02 1.
CT measurement wait time 30 to 300 ms 30
CT-03 1.
Number of CT turns 100 to 4000 turns 800
CT-04 1.
Number of CT power wire loops 1 to 6 times 1
CT-05 1.
Heater burnout detection
current value
0.0 to 350.0 A 0.0
CT-06 1.
Over-current detection cur-
rent value
0.0 to 350.0 A 0.0
CT-07 1.
Short-circuit detection value 0.0 to 350.0 A 0.0
CT-08 1.
Hysteresis 0.0 to 350.0 A 0.0
CT-09 1.
Delay time 0.0 to 3200.0 s 0.0
CT- 10 1.
Condition for restoration of
unmeasured value
1024 to 2047 (standard bit codes) 1024
CT-0 1 2.
CT operation type Same as CT input 1 0
CT-02 2.
CT measurement wait time 30
CT-03 2.
Number of CT turns 800
CT-04 2.
Number of CT power wire loops 1
CT-05 2.
Heater burnout detection
current value
0.0
CT-06 2.
Over-current detection cur-
rent value
0.0
CT-07 2.
Short-circuit detection value 0.0
CT-08 2.
Hysteresis 0.0
CT-09 2.
Delay time 0.0
CT- 10 2.
Condition for restoration of
unmeasured value
1024
 AC input bank (ac)
Display AC input number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
AC-0 1 1.
Reference voltage 4.00 to 11.00 V 10.00
AC-02 1.
Filter 0.00: No filter 0.01 to 120.00 s 0.00
AC-0 1 2.
Reference voltage Same as AC input 1 10.00
AC-02 2.
Filter 0.00
