Azbil SDC46 User Manual

2-19
Chapter 2. PARA BANK SETTINGS
Display Output number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
TPO.02 1.
Latch 0: None 1: Latch at ON
2:
Latch at OFF (except for initialization at OFF)
0
TPO.03 1.
Time proportional cycle mode 0: Priority is controllability
1: Priority is actuator service life
0
TPO.04 1.
Minimum ON/OFF time 0 to 300 ms Relay
250,
other
1
When set under 50, relay output
is 50 ms min.
When set at 0, time is 1 ms min.
(except relay output).
TPO.05 1.
Time proportional cycle 5.0 to 120.0 s for relay output
0.1 to 120.0 s for voltage pulse output
Relay
10.0,
other
2.0
TPO.06 1.
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
0
TPO.08 1.
Power voltage correction
selection
0: Disabled 1: Corrected by AC1 input
2: Corrected by AC2 input
0 Selectable on the SDC45R/46R
only.
TPO.0 1 2.
Output type Same as output 1 0 Same as output 1
TPO.02 2.
Latch 0
TPO.03 2.
Time proportional cycle mode 0
TPO.04 2.
Minimum ON/OFF time Relay
250,
other
1
TPO.05 2.
Time proportional cycle Relay
10.0,
other
2.0
TPO.06 2.
Linearization table group definition 0
TPO.08 2.
Power voltage correction selection 0
TPO.0 1 3.
Output type Same as output 1 1 Same as output 1
TPO.02 3.
Latch 0
TPO.03 3.
Time proportional cycle mode 0
TPO.04 3.
Minimum ON/OFF time Relay
250,
other
1
TPO.05 3.
Time proportional cycle Relay
10.0,
other
2.0
TPO.06 3.
Linearization table group definition 0
TPO.08 3.
Power voltage correction selection 0
TPO.0 1 4.
Output type Same as output 1 0 Same as output 1
TPO.02 4.
Latch 0
TPO.03 4.
Time proportional cycle mode 0
TPO.04 4.
Minimum ON/OFF time Relay
250,
other
1
TPO.05 4.
Time proportional cycle Relay
10.0,
other
2.0
TPO.06 4.
Linearization table group definition 0
TPO.08 4.
Power voltage correction selection 0
TPO.0 1 5.
Output type Same as output 1 0 Same as output 1
TPO.02 5.
Latch 0
TPO.03 5.
Time proportional cycle mode 0
TPO.04 5.
Minimum ON/OFF time Relay
250,
other
1
TPO.05 5.
Time proportional cycle Relay
10.0,
other
2.0
TPO.06 5.
Linearization table group definition 0
TPO.08 5.
Power voltage correction selection 0
