Azbil SDC46 User Manual

2-14
Chapter 2. PARA BANK SETTINGS
 Setup bank (Setup)
Display Auxiliary
display
Item Settings and descriptions Initial
value
User
setting
Remarks
C-00 1 -
Loop type 0: 1 loop 1: 2 loops (independent)
2: 1 loop (RSP)
3: 1 loop (computer backup)
4: 1 loop (internal cascade)
5: 2 loops (with RSP on one side of 1 loop)
6: 1 loop (computer backup with RSP)
7: 1 loop (internal cascade with RSP)
1 input
model 0,
2, 3
inputs
model 1
C-002 -
Computer backup type 0: Computer backup type 1
1: Computer backup type 2
2: Computer backup type 3
0 Cannot be set on a 1 input
model.
C-003 -
Release all latches 0: Latch is continued
1: Latch is released
0 If the "Release all latches"
function is used, set its priority
setting to "Preset value."
C-005 -
Operation display
customization
0: Standard
1: Customize
0 These items are available for
setting in firmware version 4.00
and later.
The version can be checked
in “Firmware (F/W) informa-
tion (2).”
C-006 -
PID calculation correction 0: Valid
1: Invalid
0 These items are available for
setting in firmware version 4.06
and later.
The version can be checked
in “Firmware (F/W) informa-
tion (2).”
C-009 -
SP change in operation mode 0: Change disabled
1: LSP value change disabled
2:
SP group (recipe group) change enabled
0
C-0 10 -
Use of recipe 0: Multi SP 1: Recipe 0
C-0 1 1 -
SP system group 1 to 16 1
C-0 12 -
Sampling cycle 0: 25 ms 1: 50 ms
2: 100 ms 3: 300 ms
2 Cannot be set on the SDC45V/
46V/45R/46R.
C-0 13 -
Start delay at Power ON 0 to 60 s 0
C-0 14 -
Operation display mode
screen specification
0: No change
1 to 9: Screen number of operation display
10 to 255: No change
0 Cannot be set if the operation
display change setting (
Pr-03)
in the priority bank is other
than 1.
For details on the displays, refer
to SDC45/46 Digital Indicating
Controller User’s Manual for
Installation and Configuration
(CP-SP-1218E).
C-0 15 -
Preset operation display
screen return delay
0 to 300 s 10 Cannot be set if the operation
display change setting (
Pr-03)
in the priority bank is 0.
C-0 16 -
Power frequency 0: 50 Hz 1: 60 Hz 0 Not available on AC power mod-
els (frequency is automatically
detected).
On DC power models, sets the
AC power frequency for periph-
eral devices.
C-0 17 -
Start up system 0: Cold start
1: Hot start
0 Cannot be set on the SDC45A/
46A/45R/46R.
C-0 18 -
Maximum Power failure time
for hot start
5 to 32000s 5
C-0 19 -
Power failure detection SDC45A/46A/45R/46R
0: No power interruption
1: Power interrupted
SDC45V/46V
0: No power interruption
1: Power interrupted (in excess of power
failure upper limit time for cold start
or hot start).
2: Power interrupted (for less than the hot
start power failure upper limit time).
1 Selection is fixed as "0".
C-02 1 -
Advanced function display password 1 00000 to 0FFFF (hexadecimal value) 00000 A setting for special functions.
Normally set at 00000.
C-022 -
Advanced function display password 2
C-023 -
Advanced function display password 3
C-024 -
Advanced function display password 4
C-025 -
Advanced function display password 5
C-026 -
Advanced function display password 6
