2-1
Chapter 2. PARA BANK SETTINGS
 Mode bank (MODE)
Display Loop number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
r---r L. 1.
RUN/READY
rUn : RUN mode
rdy : READY mode
RUN
A---M L. 1.
AUTO/MANUAL
AutO : AUTO mode
Man : MANUAL mode
AUTO
At L. 1.
Auto tuning (AT) stop/start
At.Of : AT stop
At.On : AT start
AT.OF
L---r L. 1.
LSP/RSP
lSp : LSP mode
rSp : RSP mode
LSP
Cb L. 1.
Backup/Through output
lMv : Backup mode (local MV)
rMv : Through output mode (remote MV)
LMV
r---r L.2.
RUN/READY
rUn : RUN mode
rdy : READY mode
RUN
A---M L.2.
AUTO/MANUAL
AutO : AUTO mode
Man : MANUAL mode
AUTO
At L.2.
Auto tuning (AT) stop/start
At.Of : AT stop
At.On : AT start
AT.OF
L---r L.2.
LSP/RSP
lSp : LSP mode
rSp : RSP mode
LSP
Cb L.2.
(Reserved for future use) - Setting is disabled.
 Loop 1 PID bank (L 1.PI D)
Display Loop number
(auxiliary display)
Item PID
value
Settings and descriptions Initial
value
User
setting
Remarks
p-0 1 L. 1.
Proportional band 1 0.1 to 3200.0 % 5.0
i -0 1 L. 1.
Integral time 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no integral control action
when set at 0, 0.0 or 0.00.)
120 The decimal point position is
determined by the decimal
point positions for the integral
time and derivative time.
d-0 1 L. 1.
Derivative time 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no derivative control action
when set at 0, 0.0 or 0.00.)
30
OL-0 1 L. 1.
Output low limit 1 -10.0 to +110.0 % 0.0
Oh-0 1 L. 1.
Output high limit 1 100.0
re-0 1 L. 1.
Manual reset 1 50.0
p-0 1c L. 1.
Proportional band for cool side 1 0.1 to 3200.0 % 5.0
i -0 1c L. 1.
Integral time for cool side 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no integral control action
when set at 0, 0.0 or 0.00.)
120 The decimal point position is
determined by the decimal
point positions for the integral
time and derivative time.
d-0 1C L. 1.
Derivative time for cool side 1 0 to 32000 s, 0.0 to 3200.0 s or 0.00 to
320.00 s (no derivative control action
when set at 0, 0.0 or 0.00.)
30
OL.0 1C L. 1.
Output low limit for cool side 1 -10.0 to +110.0 % 0.0
OH.0 1C L. 1.
Output high limit for cool side 1 100.0
P-02 L. 1.
Proportional band 2 Same as PID1 5.0 Same as PID1
i -02 L. 1.
Integral time 2 120
d-02 L. 1.
Derivative time 2 30
OL-02 L. 1.
Output low limit 2 0.0
OH-02 L. 1.
Output high limit 2 100.0
rE-02 L. 1.
Manual reset 2 50.0
P-02C L. 1.
Proportional band for cool side 2 5.0
i -02C L. 1.
Integral time for cool side 2 120
d-02C L. 1.
Derivative time for cool side 2 30
OL.02C L. 1.
Output low limit for cool side 2 0.0
OH.02C L. 1.
Output high limit for cool side 2 100.0
P-03 L. 1.
Proportional band 3 Same as PID1 5.0 Same as PID1
i -03 L. 1.
Integral time 3 120
d-03 L. 1.
Derivative time 3 30
OL-03 L. 1.
Output low limit 3 0.0
OH-03 L. 1.
Output high limit 3 100.0
rE-03 L. 1.
Manual reset 3 50.0
P-03C L. 1.
Proportional band for cool side 3 5.0
i -03C L. 1.
Integral time for cool side 3 120
d-03C L. 1.
Derivative time for cool side 3 30
OL.03C L. 1.
Output low limit for cool side 3 0.0
OH.03C L. 1.
Output high limit for cool side 3 100.0
