Azbil SDC46 User Manual

2-8
Chapter 2. PARA BANK SETTINGS
 Event configuration bank (evcnf)
Display Event number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
EP-0 1 0 1.
Operation type 0: No event 1: PV high limit 2: PV low limit
3: PV high/low limit 4: Deviation high limit
5: Deviation low limit 6: Deviation high/low limit
7: Deviation high limit (final SP reference)
8: Deviation low limit (final SP reference)
9:
Deviation high/low limit (final SP reference)
10: SP high limit 11:SP low limit
12: SP high/low limit 13: MV high limit
14: MV low limit 15: MV high/low limit
16: MFB high/low limit 17 to 25: Undefined
26: Standard numerical bit high limit
27: Standard numerical bit low limit
28: Standard numerical bit high/low limit
29 to 60: Undefined 61: Alarm (status)
62: READY (status) 63: MANUAL(status)
64: RSP (status) 65: AT start (status)
66: During SP ramp (status)
67: Control direct action (status)
68: Through output (status)
69: Undefined 70: Timer (status)
0 Setting range is 0 to 255.
Refer to  Event operation
types, polarity, hysteresis, main
settings and sub settings in
the installation and configura-
tion manual (Document No.
CP-SP-1218E).
EP-02 0 1.
Loop/channel definition 1: Loop 1 2: Loop 2 1 Setting range is 0 to 99.
EP-03 0 1.
Direct/reverse 0: Direct 1: Reverse 0
EP-04 0 1.
Standby 0: None 1: Standby
2: Standby + Standby at SP change
0
EP-05 0 1.
EVENT state at READY 0: Continued 1: Forced OFF 0
EP-06 0 1.
Decimal point position 0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
0
EP-07 0 1.
Hysteresis 0 to 32000U 5 The decimal point position is
determined by the decimal point
position for event configuration.
EP-08 0 1.
ON delay 0.0 to 3200.0s 0.0
EP-09 0 1.
OFF delay 0.0
EP-0 1 02.
Operation type Same as event 1 0 Same as event 1
EP-02 02.
Loop/channel definition 1
EP-03 02.
Direct/reverse 0
EP-04 02.
Standby 0
EP-05 02.
EVENT state at READY 0
EP-06 02.
Decimal point position 0
EP-07 02.
Hysteresis 5
EP-08 02.
ON delay 0.0
EP-09 02.
OFF delay 0.0
EP-0 1 03.
Operation type Same as event 1 0 Same as event 1
EP-02 03.
Loop/channel definition 1
EP-03 03.
Direct/reverse 0
EP-04 03.
Standby 0
EP-05 03.
EVENT state at READY 0
EP-06 03.
Decimal point position 0
EP-07 03.
Hysteresis 5
EP-08 03.
ON delay 0.0
EP-09 03.
OFF delay 0.0
EP-0 1 04.
Operation type Same as event 1 0 Same as event 1
EP-02 04.
Loop/channel definition 1
EP-03 04.
Direct/reverse 0
EP-04 04.
Standby 0
EP-05 04.
EVENT state at READY 0
EP-06 04.
Decimal point position 0
EP-07 04.
Hysteresis 5
EP-08 04.
ON delay 0.0
EP-09 04.
OFF delay 0.0
