Azbil SDC46 User Manual

2-40
Chapter 2. PARA BANK SETTINGS
 User-defined operation display creation bank (UdESI )
Display Operation
display No.
(Auxiliary
display)
Item Settings and descriptions Initial
value
User
setting
Remarks
Udd-1 0 1.
Upper display: Lit 0: Lit
1: Blinking
2: Off
0 If “Operation display custom-
ization” (
C-005) in the setup
bank is set to “1,” these items
are displayed and can be set.
These items are available for
setting in firmware version
4.00 and later.
The version can be checked
in “Firmware (F/W) informa-
tion (2).”
Udd-2 0 1.
Upper display: Displayed data 0 to 3071
 Standard numerical codes (P.4-3)
If “0” (Invalid) is set, “-----” is displayed.
0
Udd-3 0 1.
Lower display: Lit 0: Lit
1: Flashing
2: Off
3: The lower and auxiliary displays are
turned off.
0
Udd-4 0 1.
Lower display display data 0 to 3071
 Standard numerical codes (P.4-3)
If “0” (Invalid) is set, “-----” is displayed.
0
Udd- 1 02.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 02.
Upper display: Displayed data 0
Udd-3 02.
Lower display: Lit 0
Udd-4 02.
Lower display: Displayed data 0
Udd- 1 03.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 03.
Upper display: Displayed data 0
Udd-3 03.
Lower display: Lit 0
Udd-4 03.
Lower display: Displayed data 0
Udd- 1 04.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 04.
Upper display: Displayed data 0
Udd-3 04.
Lower display: Lit 0
Udd-4 04.
Lower display: Displayed data 0
Udd- 1 05.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 05.
Upper display: Displayed data 0
Udd-3 05.
Lower display: Lit 0
Udd-4 05.
Lower display: Displayed data 0
Udd- 1 06.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 06.
Upper display: Displayed data 0
Udd-3 06.
Lower display: Lit 0
Udd-4 06.
Lower display: Displayed data 0
Udd- 1 07.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 07.
Upper display: Displayed data 0
Udd-3 07.
Lower display: Lit 0
Udd-4 07.
Lower display: Displayed data 0
Udd- 1 08.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 08.
Upper display: Displayed data 0
Udd-3 08.
Lower display: Lit 0
Udd-4 08.
Lower display: Displayed data 0
Udd- 1 09.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 09.
Upper display: Displayed data 0
Udd-3 09.
Lower display: Lit 0
Udd-4 09.
Lower display: Displayed data 0
Udd- 1 10.
Upper display: Lit Same as operation display No. 01. 0 Same as operation display
No. 01.
Udd-2 10.
Upper display: Displayed data 0
Udd-3 10.
Lower display: Lit 0
Udd-4 10.
Lower display: Displayed data 0
