Azbil SDC46 User Manual

2-36
Chapter 2. PARA BANK SETTINGS
Display Auxiliary
display
Item Settings and descriptions Initial
value
User
setting
Remarks
TYPE F06.
Mathematical/logical operations
Same as for F01. 0 Same as for F01.
PA-0 1 F06.
Setting 1 0.0
PA-02 F06.
Setting 2 0.0
PA-03 F06.
Setting 3 0
DI .SEL F06.
Contact input 1024
DI F06.
Contact input monitor -
DO F06.
Contact output monitor -
OUT F06.
Computation unit output
check point value
-
TYPE F07.
Mathematical/logical operations 0: NOP No operation
1: FLT First-order lag filter
2: R/B Ratio/bias
3: HLL High/low limiter
4: DRL Change rate limiter
5: LED Differentiation
6: L/L Advance/delay
7: ABS Absolute value
8: TBL Linearization table
9: MAX Maximum value hold
10: MIN Minimum value hold
11: HLD Hold
12: PRS Preset value
13: SPR Soft preset value
14 to 30: No operation
31: ADD Addition/subtraction
32: MUL Multiplication
33: DIV Division
34: HSE High selector
35: LSE Low selector
36: SWS Switch selector
37: CPS Change point selector
38: SSS Soft switching selector
0 14 to 38 can be set with compu-
tation unit 07 only.
PA-0 1 F07.
Setting 1 -19999 to +32000 U 0.0 The decimal point position is
determined by the setting for
the decimal point position in
the input computation bank.
PA-02 F07.
Setting 2 0.0
PA-03 F07.
Setting 3 0 to 255 0
DI .SEL F07.
Contact input 1024 to 2047 1024 For more details on the 1024 to
2047 range, see the Standard
bit codes (P.4-1).
DI F07.
Contact input monitor 0: OFF 1: ON -
DO F07.
Contact output monitor -
OUT F07.
Computation unit output
check point value
-19999 to +32000 U - The decimal point position is
determined by the setting for
the decimal point position in
the input computation bank.
TYPE F08.
Mathematical/logical operations Same as for F01. 0 Same as for F01.
PA-0 1 F08.
Setting 1 0.0
PA-02 F08.
Setting 2 0.0
PA-03 F08.
Setting 3 0
DI .SEL F08.
Contact input 1024
DI F08.
Contact input monitor -
DO F08.
Contact output monitor -
OUT F08.
Computation unit output
check point value
-
TYPE F09.
Mathematical/logical operations Same as for F01. 0 Same as for F01.
PA-0 1 F09.
Setting 1 0.0
PA-02 F09.
Setting 2 0.0
PA-03 F09.
Setting 3 0
DI .SEL F09.
Contact input 1024
DI F09.
Contact input monitor -
DO F09.
Contact output monitor -
OUT F09.
Computation unit output
check point value
-
TYPE F 10.
Mathematical/logical operations Same as for F01. 0 Same as for F01.
PA-0 1 F 10.
Setting 1 0.0
PA-02 F 10.
Setting 2 0.0
PA-03 F 10.
Setting 3 0
DI .SEL F 10.
Contact input 1024
DI F 10.
Contact input monitor -
DO F 10.
Contact output monitor -
OUT F 10.
Computation unit output
check point value
-
