2-35
Chapter 2.  PARA BANK SETTINGS
  Output computation bank (OT.FNC)
Display Auxiliary
display
Item Settings and descriptions Initial
value
User
setting
Remarks
DP F0 1.
Decimal point position  0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
1
I N.0 1 F0 1.
Input 1  2048 to 3071 2048 For more details on the 2048 to
3071 range, see the Standard
numerical codes (P.4-3).
I N.02 F0 1.
Input 2  2048
TYPE F0 1.
Mathematical/logical operations
0: NOP  No operation
1: FLT  First-order lag filter
2: R/B  Ratio/bias
3: HLL  High/low limiter
4: DRL  Change rate limiter
5: LED  Differentiation
6: L/L  Advance/delay
7: ABS  Absolute value
8: TBL  Linearization table
9: MAX  Maximum value hold
10: MIN  Minimum value hold
11: HLD  Hold
12: PRS  Preset value
13: SPR  Soft preset value
0
PA-0 1 F0 1.
Setting 1  -19999 to +32000 U 0.0 The decimal point position is
determined by the setting for
the decimal point position in
the input computation bank.
PA-02 F0 1.
Setting 2  0.0
PA-03 F0 1.
Setting 3  0 to 255 0
DI .SEL F0 1.
Contact input  1024 to 2047 1024 For more details on the 1024 to
2047 range, see the Standard
bit codes (P.4-1).
DI F0 1.
Contact input monitor  0: OFF  1: ON -
DO F0 1.
Contact output monitor  -
OUT F0 1.
Computation unit output
check point value
-19999 to +32000 U - The decimal point position is
determined by the setting for
the decimal point position in
the input computation bank.
TYPE F02.
Mathematical/logical operations
Same as for F01. 0 Same as for F01.
PA-0 1 F02.
Setting 1  0.0
PA-02 F02.
Setting 2  0.0
PA-03 F02.
Setting 3  0
DI .SEL F02.
Contact input  1024
DI F02.
Contact input monitor  -
DO F02.
Contact output monitor  -
OUT F02.
Computation unit output
check point value
-
TYPE F03.
Mathematical/logical operations
Same as for F01. 0 Same as for F01.
PA-0 1 F03.
Setting 1  0.0
PA-02 F03.
Setting 2  0.0
PA-03 F03.
Setting 3  0
DI .SEL F03.
Contact input  1024
DI F03.
Contact input monitor  -
DO F03.
Contact output monitor  -
OUT F03.
Computation unit output
check point value
-
TYPE F04.
Mathematical/logical operations
Same as for F01. 0 Same as for F01.
PA-0 1 F04.
Setting 1  0.0
PA-02 F04.
Setting 2  0.0
PA-03 F04.
Setting 3  0
DI .SEL F04.
Contact input  1024
DI F04.
Contact input monitor  -
DO F04.
Contact output monitor  -
OUT F04.
Computation unit output
check point value
-
TYPE F05.
Mathematical/logical operations
Same as for F01. 0 Same as for F01.
PA-0 1 F05.
Setting 1  0.0
PA-02 F05.
Setting 2  0.0
PA-03 F05.
Setting 3  0
DI .SEL F05.
Contact input  1024
DI F05.
Contact input monitor  -
DO F05.
Contact output monitor  -
OUT F05.
Computation unit output
check point value
-
