Azbil SDC46 User Manual

2-17
Chapter 2. PARA BANK SETTINGS
Display PV input number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
Pv-06 2.
Cold junction compensation 0: Performed (internal)
1: Not performed (external)
2: Terminal temperature compensation is
done by a sensor on another channel.
0
Pv-07 2.
Zener barrier adjustment -20.00 to +20.00 Ω 0.00 Set by means of the adjustment
procedure.
Cannot be set by direct input
of a numerical value using
the keys.
Pv-09 2.
Linear scaling low limit -19999 to +32000 U 0.0 The decimal point position is
determined by the decimal point
position for the PV.
Pv- 10 2.
Linear scaling high limit 1000.0
Pv- 1 1 2.
Square root extraction
dropout
0.0: Square root extraction is not per-
formed 0.1 to 10.0 %
0.0
Pv- 12 2.
Filter 0.00: No filter 0.01 to 120.00 s 0.00
Pv- 13 2.
Bias -19999 to +32000 U 0.0 The decimal point position is
determined by the decimal point
for the PV.
Pv- 14 2.
Ratio 0.001 to 32.000 1.000
Pv- 16 2.
Thermocouple mV input
burnout
0: Upscale at burnout
1: No burnout detection
0
Pv-20 2.
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
0
Pv-0 1 3.
Range type 0: Not used
49: 1 to 5 V 50: 0 to 5 V 51: 0 to 10 V
51 For details, refer to the PV input
range table in the SDC45/46
Installation Instructions (No. CP-
UM-5445E). Be sure not to set a
range type number that is not
supported.
Pv-02 3.
Decimal point position 0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
4: 4 digits after decimal point
1
Pv-03 3.
Temperature unit - -
Pv-04 3.
Range low limit -19999 to +32000 U -1999.9 The decimal point position is
determined by the decimal point
position for the PV.
Pv-05 3.
Range high limit 3200.0
Pv-06 3.
Cold junction compensation - -
Pv-07 3.
Zener barrier adjustment - - Set by means of the adjustment
procedure.
Cannot be set by direct input of
a numerical value using the keys.
Pv-09 3.
Linear scaling low limit -19999 to +32000 U 0.0 The decimal point position is
determined by the decimal point
position for the PV.
Pv- 10 3.
Linear scaling high limit 1000.0
Pv- 1 1 3.
Square root extraction
dropout
0.0: Square root extraction is not per-
formed 0.1 to 10.0 %
0.0
Pv- 12 3.
Filter 0.00: No filter 0.01 to 120.00 s 0.00
Pv- 13 3.
Bias -19999 to +32000 U 0.0 The decimal point position is
determined by the decimal point
position for the PV.
Pv- 14 3.
Ratio 0.001 to 32.000 1.000
Pv- 16 3.
Thermocouple mV input
burnout
- -
Pv-20 3.
Linearization table group
definition
0: Disabled 1: Group 1 2: Group 2
3: Group 3 4: Group 4 5: Group 5
6: Group 6 7: Group 7 8: Group 8
0
