Azbil SDC46 User Manual

2-26
Chapter 2. PARA BANK SETTINGS
Display Linearization
group number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
tb.b.01 8.
Breakpoint B1 Same as linearization 1 -1999.9 Same as linearization 1
tb.b.02 8.
Breakpoint B2 3200.0
tb.b.03 8.
Breakpoint B3 0.0
tb.b.04 8.
Breakpoint B4
tb.b.05 8.
Breakpoint B5
tb.b.06 8.
Breakpoint B6
tb.b.07 8.
Breakpoint B7
tb.b.08 8.
Breakpoint B8
tb.b.09 8.
Breakpoint B9
tb.b. 10 8.
Breakpoint B10
tb.b. 1 1 8.
Breakpoint B11
tb.b. 12 8.
Breakpoint B12
tb.b. 13 8.
Breakpoint B13
tb.b. 14 8.
Breakpoint B14
tb.b. 15 8.
Breakpoint B15
tb.b. 16 8.
Breakpoint B16
tb.b. 17 8.
Breakpoint B17
tb.b. 18 8.
Breakpoint B18
tb.b. 19 8.
Breakpoint B19
tb.b.20 8.
Breakpoint B20
 Internal contact input bank (i c)
Display Internal contact
input number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
I C-0 1 0 1.
Operation type 0: No function 1: SP group selection
2: PID group selection
3: Fixed value output selection
4: Multi ratio selection
5: Linearization use group selection
(for output)
21: RUN/READY selection
22: AUTO/MANUAL selection
23: LSP/RSP selection
24: AT Stop/Start selection
25: Backup/through output selection
41: Control action direct/reverse
selection
42: SP ramp enabled/disabled selection
43: Operation display selection
46: Timer Stop/Start selection
47: Release all latches
0
I C-02 0 1.
Input type 1024: OFF 1025: ON 1152: DI-C1
1153: DI-C2 1154: DI-C3 1155: DI-C4
1156: DI-C5 1157: DI-C6 1158: DI-C7
1159: DI-C8 1176: DI-F1 1177: DI-F2
Others
1152 Setting range is 1024 to 2047.
For details, refer to Standard bit
codes (P.4-1).
I C-03 0 1.
Loop/channel definition 0: All loops 1: Loop 1 2: Loop 2
(the meaning is different depending on
the operation type)
1 Setting range is 0 to 127.
For details, refer to  Operation
type (CP-SP-1218E) in the
installation and configuration
manual.
I C-04 0 1.
Weight 0 to 127 1
I C-0 1 02.
Operation type Same as internal contact 1 input 0 Same as internal contact 1 input
I C-02 02.
Input type 1153
I C-03 02.
Loop/channel definition 1
I C-04 02.
Weight 1
I C-0 1 03.
Operation type Same as internal contact 1 input 0 Same as internal contact 1 input
I C-02 03.
Input type 1154
I C-03 03.
Loop/channel definition 1
I C-04 03.
Weight 1
I C-0 1 04.
Operation type Same as internal contact 1 input 0 Same as internal contact 1 input
I C-02 04.
Input type 1155
I C-03 04.
Loop/channel definition 1
I C-04 04.
Weight 1
