Chapter 2. PARA BANK SETTINGS
Digital output bank (dO)
Display
Digital output
number
(auxiliary display)
Item Digital
output
column
Settings and descriptions Initial
value
User
setting
Remarks
dO.c.0 1 1.
Output type
Column C
1024: OFF 1025: ON
1088: Event 1 1089: Event 2
1090: Event 3 1091: Event 4
1092: Event 5 1093: Event 6
1094: Event 7 1095: Event 8
1096: Event 9 1097: Event 10
1098: Event 11 1099: Event 12
1100: Event 13 1101: Event 14
1102: Event 15 1103: Event 16
Others
1024 Setting range is 1024 to 2047.
For details, refer to: Standard bit
codes (P.4-1).
dO.c.02 1.
Latch Column C 0: None 1: Latch at ON
2: Latch at OFF
(except for initialization at OFF)
0
dO.c.0 1 2.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 2.
Latch Column C 0
dO.c.0 1 3.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 3.
Latch Column C 0
dO.c.0 1 4.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 4.
Latch Column C 0
dO.c.0 1 5.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 5.
Latch Column C 0
dO.c.0 1 6.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 6.
Latch Column C 0
dO.c.0 1 7.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 7.
Latch Column C 0
dO.c.0 1 8.
Output type Column C Same as digital output column C 1 1024 Same as digital output column C 1
dO.c.02 8.
Latch Column C 0
dO.e.0 1 1.
Output type Column E 1024: OFF 1025: ON
1088: Event 1 1089: Event 2
1090: Event 3 1091: Event 4
1092: Event 5 1093: Event 6
1094: Event 7 1095: Event 8
1096: Event 9 1097: Event 10
1098: Event 11 1099: Event 12
1100: Event 13 1101: Event 14
1102: Event 15 1103: Event 16
Others
1024 Setting range is 1024 to 2047.
For details, refer to: Standard bit
codes (P.4-1).
dO.e.02 1.
Latch Column E 0: None 1: Latch at ON
2: Latch at OFF
(except for initialization at OFF)
0
dO.e.0 1 2.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 2.
Latch Column E 0
dO.e.0 1 3.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 3.
Latch Column E 0
dO.e.0 1 4.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 4.
Latch Column E 0
dO.e.0 1 5.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 5.
Latch Column E 0
dO.e.0 1 6.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 6.
Latch Column E 0
dO.e.0 1 7.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 7.
Latch Column E 0
dO.e.0 1 8.
Output type Column E Same as digital output column E 1 1024 Same as digital output column E 1
dO.e.02 8.
Latch Column E 0
