Azbil SDC46 User Manual

2-31
Chapter 2. PARA BANK SETTINGS
Display Logical opera-
tion number
(auxiliary display)
Item Settings and descriptions Initial
value
User
setting
Remarks
bF-0 1 10.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 10.
Input assignment A 1024
bF-03 10.
Input assignment B
bF-04 10.
Input assignment C
bF-05 10.
Input assignment D
bF-06 10.
Input bit polarity A 0
bF-07 10.
Input bit polarity B
bF-08 10.
Input bit polarity C
bF-09 10.
Input bit polarity D
bF- 10 10.
ON delay time 0.0
bF- 1 1 10.
OFF delay time
bF- 12 10.
Polarity 0
bF- 13 10.
Latch 0
bF-0 1 1 1.
Operation type Same as logical operation 1
1
Same as logical operation 1
bF-02 1 1.
Input assignment A 1024
bF-03 1 1.
Input assignment B
bF-04 1 1.
Input assignment C
bF-05 1 1.
Input assignment D
bF-06 1 1.
Input bit polarity A 0
bF-07 1 1.
Input bit polarity B
bF-08 1 1.
Input bit polarity C
bF-09 1 1.
Input bit polarity D
bF- 10 1 1.
ON delay time 0.0
bF- 1 1 1 1.
OFF delay time
bF- 12 1 1.
Polarity 0
bF- 13 1 1.
Latch 0
bF-0 1 12.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 12.
Input assignment A 1024
bF-03 12.
Input assignment B
bF-04 12.
Input assignment C
bF-05 12.
Input assignment D
bF-06 12.
Input bit polarity A 0
bF-07 12.
Input bit polarity B
bF-08 12.
Input bit polarity C
bF-09 12.
Input bit polarity D
bF- 10 12.
ON delay time 0.0
bF- 1 1 12.
OFF delay time
bF- 12 12.
Polarity 0
bF- 13 12.
Latch 0
bF-0 1 13.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 13.
Input assignment A 1024
bF-03 13.
Input assignment B
bF-04 13.
Input assignment C
bF-05 13.
Input assignment D
bF-06 13.
Input bit polarity A 0
bF-07 13.
Input bit polarity B
bF-08 13.
Input bit polarity C
bF-09 13.
Input bit polarity D
bF- 10 13.
ON delay time 0.0
bF- 1 1 13.
OFF delay time
bF- 12 13.
Polarity 0
bF- 13 13.
Latch 0
bF-0 1 14.
Operation type Same as logical operation 1 1 Same as logical operation 1
bF-02 14.
Input assignment A 1024
bF-03 14.
Input assignment B
bF-04 14.
Input assignment C
bF-05 14.
Input assignment D
bF-06 14.
Input bit polarity A 0
bF-07 14.
Input bit polarity B
bF-08 14.
Input bit polarity C
bF-09 14.
Input bit polarity D
bF- 10 14.
ON delay time 0.0
bF- 1 1 14.
OFF delay time
bF- 12 14.
Polarity 0
bF- 13 14.
Latch 0
