Chapter 3. SP/EV BANK SETTINGS
 RSP bank (RSP)
Display Loop number
( auxiliary display )
Item Settings and descriptions Initial
value
User
setting
Remarks
rSP L. 1.
RSP Display is enabled, and setting is disabled -
PID L. 1.
PID group definition 1 to 16 1
rSP L.2.
RSP Display is enabled, and setting is disabled -
PID L.2.
PID group definition 1 to 16 1
 Event setup bank (EV)
Display Auxiliary display Item Event
number
Settings and descriptions Initial
value
User
setting
Remarks
E0 1
- Event main setting 1 -19999 to +32000 U 0 The decimal point position is
determined by the decimal
point position for the event
configuration.
E0 1.SB
- Event sub setting 1
E02
- Event main setting 2
E02.SB
- Event sub setting 2
E03
- Event main setting 3
E03.SB
- Event sub setting 3
E04
- Event main setting 4
E04.SB
- Event sub setting 4
E05
- Event main setting 5
E05.SB
- Event sub setting 5
E06
- Event main setting 6
E06.SB
- Event sub setting 6
E07
- Event main setting 7
E07.SB
- Event sub setting 7
E08
- Event main setting 8
E08.SB
- Event sub setting 8
E09
- Event main setting 9
E09.SB
- Event sub setting 9
E 10
- Event main setting 10
E 10.SB
- Event sub setting 10
E 1 1
- Event main setting 11
E 1 1.SB
- Event sub setting 11
E 12
- Event main setting 12
E 12.SB
- Event sub setting 12
E 13
- Event main setting 13
E 13.SB
- Event sub setting 13
E 14
- Event main setting 14
E 14.SB
- Event sub setting 14
E 15
- Event main setting 15
E 15.SB
- Event sub setting 15
E 16
- Event main setting 16
E 16.SB
- Event sub setting 16
