BAFANG MAX Drive System - 4.3 Crank Installation

36
CHAIN GUARD INSTALLATION
DEALER MANUAL MAX DRIVE SYSTEM
E
screw M5
F
p-shaped chain guard
Install the p-shaped chain guard as shown in the drawing.
The drawing above shows the mounted p-shaped chain guard.
Not all p-shaped chain guards are compatible with the MAX drive unit.
