BAFANG MAX Drive System User Manual

8
DRIVE UNIT (MM G33.350)
DEALER MANUAL MAX DRIVE SYSTEM
1.4 Main Technical Parameters
Rated voltage (DCV) 36 / 43
Rated power (W) 250 350 / 250 350
Rated efficiency (%) ≥ 80%
Rated rotating speed (rpm) 100 ± 5
Maximum torque (Nm) ≥ 80
Chain wheel 36T (recommended), 38T (optional), 42T (optional)
Optional chain guard full chain guard / P-shaped chain guard
Weight (Kg) 3.9
Sensors
pedal assist speed sensor, pedal assist torque sensor and bicycle wheel
speed sensor and temperature sensor
Noise (dB) < 55
Working environment -20°C~55°C
Dust-proof/ water-proof grade IP 66
Certification CE ROHS/ EN14766/ EN14764/ REACH
Functions
Light function: DC 500mA/6V headlight & rearlight
Optional functions: Bluetooth module, gear sensor, reprogramming function
