BAFANG MAX Drive System User Manual

57
DEALER MANUAL MAX DRIVE SYSTEM
7.2.2 Motor Cover Accessories
Name Material No. Quantity Specification
Motor cover 1333000000001 1
Cable gatherer 1401150100005 2
cross head screw assembly M3×8 1401020000127 2 M3×8
7.2.3 Chain Guard Assembly Module
Name Material No. Quantity Specification
Full chain guard binder plate 1401150100004 1
P-shaped chain guard holder 1401220200003 1
M4 cross recessed pan head screw 1401020000111 M4×8
7.2.4 Chain Wheel Module
Name Material No. Quantity Specification
Chain wheel Module A 1325020000001 CL-49 mm/38 T
Chain wheel Module B (optional) 1325020000002 CL-45 mm/38 T
Chain wheel Module C (optional) 1325020000003 CL-48 mm/38 T
7.2.5 Crank Components
Name Material No. Quantity Specification
Right straight crank with a cover 1327040000001 1 170 mm
Right straight crank (optional) 1327010000001 1 170 mm
Left straight crank 1327020000001 1 170 mm
Crank mounting screws 1401020000109 2 M8
