SECTION 3 - INSTALLATION
INTRODUCTION
Completely install and prepare (i.e., attach wiring to terminal
blocks, etc.) the hardware before applying power. This section
explains hardware preparation in detail.
NOTE:
Normally, the cabinet is fully wired and ready to go upon
receipt. The following information is provided in the event that you
need to repair, replace, wire, or add to the modular power system.
UNPACKING AND INSPECTION
The power modules are in separate packages from the rest of
the power system. Handle these modules per the steps in Spe-
cial Handling and General Handling.
Special Handling
The power supply module, DC transfer module and bus moni-
tor module use devices susceptible to electrostatic discharge.
Follow these handling procedures:
NOTE:
Always use Bailey Controls field static kit (part number
1948385_1 - consisting of two wrist straps, ground cord assembly,
alligator clip, and static dissipative work surface) when working with
the modules. The kit grounds a technician and the static dissipative
work surface to the same ground point to prevent damage to the
modules by electrostatic discharge.
1. Use Static Shielding Bag. Keep the modules in the static
shielding bag until you are ready to install them in the system.
Save the bag for future use.
2. Ground Bag before Opening. Before opening a bag con-
taining an assembly with semiconductor devices, touch it to
the equipment housing or a ground to equalize charges.
3. Avoid Touching Circuitry. Handle assemblies by the
edges; avoid touching the circuitry.
4. Avoid Partial Connection of Semiconductor Device.
Verify that all devices connected to the modules are properly
grounded before using them.
5. Ground Test Equipment.
6. Use an Antistatic Field Service Vacuum. Remove dust
from the module if necessary.
