OPERATING PROCEDURES
RECOMMENDED START-UP PROCEDURES
I-E96-508C 4 - 3
7. Continue adding process control modules until the system
cabinet is filled.
8. Measure the voltages when the system cabinet is filled and
verify that they are within the acceptable levels in Step 5. Refer
to Table 1-4 for power module outputs under load.
NOTE:
A red status light at this point may indicate an overload con-
dition or defective module. If this happens, replace the suspect
power module. If the condition still exists, add power modules to
meet the system current requirements. Use the procedures in
Appendix B to size the power system.
9. For optimum cooling, put blank faceplate (Bailey Controls
part number 6636586_1) in any unused slots.
Table 4-2. Typical Unloaded DC Bus Output
Voltage Requirements
5 VDC 24 VDC +15 VDC -15 VDC
Min Max Min Max Min Max Min Max
5.1 5.25 25.5 27 15 15.75 -15 -15.75
