MODULAR POWER SYSTEM SIZING TABLES
INTRODUCTION
D - 2 I-E96-508C
®
Use Table D-2 to size systems that use both the IEPDS01 and
IEPDS02 and IEPDF01 and IEPDF02 modules. Table D-2 lists
two values (Q1 and QF) for the 5 VDC and 24 VDC (A and B)
current requirements. The value of Q1 indicates how many
PDS modules are needed to meet system requirements. The
value of QF indicates how many PDF modules are needed to
meet system requirements.
Table D-2. Q1 and QF for Systems Using IEPDS01/02 and IEPDF01/02 Modules
A
B
024681012141618202224262830
0Q1
0000000000000000
QF
0112233445566778
5Q1
1111111222222222
QF
0011223344556677
10 Q1
1112222222222333
QF
0010122344566566
15 Q1
2222222333333333
QF
0001223233455677
20 Q1
2222233333333444
QF
0001212334566566
25 Q1
3333333334444444
QF
0000123343445677
30 Q1
3333333444444455
QF
0000123234456756
35 Q1
4444444444455555
QF
0000012344545567
40 Q1
4444444445555555
QF
0000012343455678
45 Q1
5555555555555666
QF
0000001234556566
50 Q1
5555555555566666
QF
0000001234545667
55 Q1
6666666666666667
QF
0000000123456676
60 Q1
6666666666666777
QF
0000000123456567
65 Q1
7777777777777777
QF
000000001234 5677
70 Q1
7777777777777778
QF
0000000012345676
75 Q1
8888888888888888
QF
0000000001234567
