INTRODUCTION
I-E96-508C A - 1
APPENDIX A - QUICK REFERENCE MATERIAL
INTRODUCTION
Use Table A-1 as a quick reference to check switch and jumper
settings on the, IEPDF01, IEPDF02, IEPDS01 and IEPDS02
modules, bus monitor module, and DC transfer module. Fig-
ures 3-3, 3-4, and 3-5 show DC transfer module, bus monitor
module, and power module board layout.
Table A-1. Switch and Jumper Setting Reference Guide
Device
Dipswitch
Settings
Jumper
Position
Function
Bus monitor
module
S1-0011 Factory default setting, 5 VDC, ±15 VDC, and 24
VDC monitoring enabled. External power monitoring
disabled.
J1
1-2
2-4
2-3
Auxiliary bus monitor, channel 1:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J2
1-2
2-4
2-3
Auxiliary bus monitor, channel 2:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J3
2-3 Jumper must be installed in this position
J4
1-2
2-3
3-4
Auxiliary status input 1:
Normally open status input
Normally closed status input
PFI (NO)
J5
1-2
2-3
Auxiliary status input 2:
Normally open status input
Normally closed input
J6
1-2
2-3
Input power isolation:
Do not isolate input power
Isolate input power
J7
2-3 Jumper must be installed in this position
J8
1
1-2
2-3
Input common isolation:
Isolate input common from output common
Do not isolate input common from output common
DC transfer
module
J1
1-4
2-4
Input power, line 1:
24 VDC high detect
48 VDC high detect
J2
1-4
2-4
Input power, line 1:
24 VDC low detect
48 VDC low detect
