INSTALLATION
IEPMU01/02 POWER MOUNTING UNIT INSTALLATION
I-E96-508C 3 - 11
•
Avoid touching the circuitry when handling the module.
•
Always use grounding straps (field static kits) when work-
ing with the modules.
To install the power modules:
1. Refer to Figure 3-5 to set jumper J2 for module type and
J3 for bus voltage monitoring.
2. Grasp the module faceplate handle and align the top and
bottom edges of the circuit board with the guides in the mod-
ule mounting unit or power mounting unit.
3. Hold the module by the faceplate handle and slide it into
its mounting slot. Push on the module faceplate until the rear
edge connector is firmly seated in the backplane connector.
4. Firmly push on the module handle as you use a blade
screwdriver to push and turn the 2 latching screws 1/2-turn
clockwise to lock the module in place.
To remove the module, refer to
POWER MODULE REPLACE-
MENT
in Section 7 of this manual.
IEPMU01/02 POWER MOUNTING UNIT INSTALLATION
Required Tools
You will need these tools to install the power mounting unit:
•
16-inch flat screwdriver.
•
7/16-inch nut driver.
•
Pliers.
•
Volt/ohmmeter.
•
Heat gun.
WARNING
Verify the main power and power entry panel circuit breakers
are turned off before starting installation, retrofit, upgrade, or
wiring procedures. Failure to do so could result in severe or
fatal shock. Do not turn the power on until the installation, ret-
rofit, upgrade, or wiring procedures are complete.
AVERTISSEMENT
Assurez-vous que le disjoncteur d'alimentation principal et le
disjoncteur de panneau d'entrée des alimentations sont éteints
avant de procéder à l'installation, à la mise à jour, à l'extension
ou au câblage, dans le but d'éviter les chocs sérieux et même
mortels. Ne rétablissez pas l'alimentation tant que ces procé-
dures ne sont pas terminées.
