Preface
The 24/48 VDC Modular Power System supplies system and
I/O power to the INFI 90
®
system. This manual explains how
the 24/48 VDC Modular Power System operates through sup-
portive text, diagrams and flowcharts. It provides introductory
material and specific instructions for installation, operation,
troubleshooting and maintenance of the system based on the
following:
• IECAB01 or IECAB03 system cabinets.
• IEPDS01 or IEPDS02 system power modules.
• IEPDF01 or IEPDF02 field power modules.
• IEPEP04 power entry panel.
• IEMMU01 or IEMMU02 module mounting unit.
• IEPMU01 or IEPMU02 power mounting unit.
This manual also provides information about module current
consumption so the modular power system can be sized for
your application. This instruction covers only the 24/48 VDC
Modular Power System. For information on the AC modular
power system refer to the AC Modular Power System manual.
