PRODUCT DESCRIPTION
CAUTION
!
NEVER STARE DIRECTLY INTO THE SENSOR LENS.
Laser light can damage your eyes.
• Avoid placing any mirror-like object in the beam. Never use a mirror as a retroreflective target.
Class 2 lasers are lasers that emit visible radiation in the wavelength range from 400 nm to 700 nm, where eye protection is normally afforded
by aversion responses, including the blink reflex. This reaction may be expected to provide adequate protection under reasonably foreseeable
conditions of operation, including the use of optical instruments for intrabeam viewing.
Low-power lasers are, by definition, incapable of causing eye injury within the duration of a blink (aversion response) of 0.25 seconds. They also
must emit only visible wavelengths (400 to 700 nm). Therefore, an ocular hazard may exist only if individuals overcome their natural aversion to
bright light and stare directly into the laser beam.
1.4. Features
The Q5X has three major features.
1.4.1. Display and Indicators
The display is a four-digit, seven-segment LED. Run mode is the primary view displayed.
For Safe Laser Use - Class 2 Lasers
• Do not stare at the laser.
• Do not point the laser at a person’s eye.
• Mount open laser beam paths either above or below eye level, where practical.
• Terminate the beam emitted by the laser product at the end of its useful path.
Class 2 Red Laser models: Reference IEC 60825-1:2014
Figure 1: FDA (CDRH) warning label (Class 2)
Output: < 1.0 mW
Laser wavelength: 640 to 670 nm
Pulse Duration: 20 µs to 2 ms
Figure 2: Q5X Features
1) Two output indicators (amber)
2) Display
3) Buttons
LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
IEC 60825-1:2014. Wavelength
640-670nm; 1.0mW max. Complies with
21 CFR 1040.10 and 1040.11 except for
conformance with IEC 60825-1: 2014
as described in Laser Notice
No. 56, dated May 8, 2019.
