Barco ClickShare CSE-800 Installation Manual

27R5900049 /13 ClickShare CSE-800
Regional version
Contains Accessories included
R9861580NA
• R9861580
• 4x R9861500D01
• R9861500T01
• power cable NEMA 5/15
• wall/ceiling mounting brackets
• antenna extension cables
R9861580US
• R9861580
• 4x R9861500D01
• R9861500T01
• power cable SP305 IS14 1M83
• wall/ceiling mounting brackets
• antenna extension cables
Contact your local sales representative for the correct regional variant to be used in your country.
2.2 CSE-800 specifications
Base Unit
Dimensions (HxWxD) 46.2mm x 282.3mm x 206.5mm (excl. antennas) / 1.8" x 11.1" x 8.1"
146.4mm x 282.3mm x 206.5mm (incl. antennas) / 5.8"x 11.1" x 8.1"
Power supply Standard 110/220 V AC plug
Power consumption Normal operation:
90W under full usage
52W under normal usage (connect 2 HDMI outputs, connect 1 HDMI input,
share with 4 people)
ECO mode: 30W
Networked standby mode: < 1W
Deep standby mode: < 0.5W
Weight 2.2kg / 4.85lbs
Operating system Windows 7/8/8.1/10 32 & 64 bit
macOS 10.14/10.15 (Catalina)
Android 9 & 10 (ClickShare app)
iOS 11, 12 & 13 (ClickShare app)
Video outputs 2x HDMI 1.4b
Video inputs 2x HDMI 1.4b
Output resolution 4K DCI (4096x2160) @ 60Hz
Input resolutions 4K DCI (4096x2160) @ 60Hz
Audio Via HDMI, analog via Audio Jack 3.5mm, S/PDIF
AirPlay Support iOS 11, 12 & 13 / macOS 10.14, 10.15
Google Cast Support Android 9, 10
Frame rate Using HDMI inputs:
Up to 60fps with one input @ 4K
Up to 30fps with two inputs @ 4K*
Using the ClickShare Button or Apps:
Up to 30 fps @1080p
Number of sources
simultaneous on screen
8 (4 per screen)
Number of simultaneous
connections
64 (Button and/or App)
CSE-800 Specifications

Barco ClickShare CSE-800 Specifications
