Barco ClickShare CSE-800 Installation Manual

49R5900049 /13 ClickShare CSE-800
Advantages
• Less Wi-Fi access points allowing to better control the Wi-Fi spectrum.
• Eliminates any security risks via ClickShare because all Base Units are in an isolated and separate (virtual)
LAN.
• Easy management of all ClickShare Base Units in the separate (virtual) LAN, e.g. through their assigned IP
addresses.
• If the network configuration allows it, mobile users remain connected to their current network when sharing
and have access to corporate environment and the internet. Enterprise network traffic is routed to the
dedicated ClickShare network for content sharing purposes.
How to setup via the Configurator
1. Connect the Base Unit and browse to the ClickShare Configurator and log in.
2. Select Button in the System menu and click Edit settings.
Select External Access Point from the drop down menu and select the preferred authentication mode and
fill out the details.
Click Save Changes. For more information, see “Buttons”, page 99
3. Pair the Buttons again with the Base Unit.
4. Optionally the Base Unit’s Wi-Fi can be set to Access Point or can be set to Off. For more info, “”,
Setup via XMS
1. Log in to XMS and go to the Base Units tab.
2. In the device list select the Unit(s) for deploying network integration mode and click Edit in the top right
menu..
3. Browse to System > Button Connects To in the configurator.
4. Select External Access Point from the drop-down menu.
5. Select the preferred authentication mode and fill out the details.
6. Click Save Changes when finished.
7. Re-pair the ClickShare Buttons with the updated Base Unit(s) to apply the new configuration
For more detailed information on how to use XMS, consult the XMS user guide.
4.14 Power connection and switching on
WARNING: Use a power cord which complies to local regulations. If not included in the box, contact
your local dealer for a correct power cord.
How to connect
1. Plug the power cable in the mains power connector at the back of the Base Unit
Note: The local variant of the power cable is included in the CSE-800 box.
European version Type C and type G
Japanese version Type A
Chinese version Type I CCC
North American
version
Type A
2. To power on the unit, set the rocker switch to “1”.
CSE-800 Installation
