There will be synchronization between the audio and video signal.
Audio via HDMI
When your display is connected via HDMI and it supports audio, a separate audio connection is not
necessary. The audio signal is sent together with the video signal to the display.
How to connect separate audio
1. When using the analog output via mini-jack, connect an audio cable with mini jack (3.5mm) into the analog
audio output of the Base Unit.
When using the analog out via cinch, connect an audio cable with cinch connectors into the analog audio
output of the Base Unit.
When using the digital output, connect an fibre optical cable with TOSLINK connector into the digital audio
output of the Base Unit.
2. Connect the other side to the meeting room's sound system.
Audio output needs to be selected in the Configurator, for more info, see “Audio settings”, page 75.
Sound is not sent out
In some Windows environments sound is not sent out. This can be solved as follow:
1. Right click on the sound icon in the system tray and select Playback devices. The Sound window opens.
2. Select Speakers ClickShare, select Set default and click Apply.
4.9 LAN connection
For the moment, only the primary network connector can be used for API, Management Suite and
Network Integration.
About LAN connection
The Base Unit can be connected to a local network or directly to a laptop. For normal operation, a LAN
connection is not necessary.
The LAN interface is split up in a primary interface and a secondary interface. During normal operation both
LAN inputs have the same functionality. During standby, the primary interface acts as an network standby and
the secondary interface is than switched off.
The LAN connection can be used:
• to configure your CSE-800 unit
• to update the software
• for maintenance purposes
• for network integration of your CSE-800 unit
• for network standby
CAUTION: Both LAN connections must be connected to two different networks.
How to connect
1. Insert a network cable with RJ-45 connector into the primary (LAN1) and/or the secondary (LAN2) LAN
port.
2. Connect the other side to a LAN.
3. Configure the LAN interfaces, see “LAN Settings”, page 80.
