Overview
34
Figure 12
Side
(2) USB downstream connector
(3) Control wheel for navigating through the on-screen display
(OSD) menus and changing values in the menus
Figure 13
Rear
(4) USB downstream connector
(5) USB upstream connector
(6) Digital DVI (video and data) input
(7) DC 12V power input
3
2
4 5 6
7
