R5906848 /04 DP2K SLP Series28
N-
o.
Compo-
nent
Maintenance action Remarks
11 Software
version
Check for the latest version of Barco and TI
software. See user guide of the
Communicator software. The latest
software version can be downloaded from
the secured Barco web site.
Upgrade the projector software with the
latest version. See user guide of the
projector toolset.
12 Info-T's Check if all Info-T's are implemented. Note
that the Info-T's are listed on the secured
Barco web site.
If not, implement all Info-T's and update the
projector service docket.
13 Lens
holder
Check the Lens Holder shift functionality
(up/down & left/right).
Use the local keypad or the Communicator
software to shift.
14 Lens
holder
Check the positional integrity of motorized
adjustments by switching Macro's.
Verify correct alignment on screen between
flat and scope.
15 Lens
holder
Check the focus uniformity. Adjust the Lens Holder (Scheimpflug)
ONLY if needed. See service manual
chapter “Scheimpflug”, page 199.
16 Lens Check the optic surfaces of the lens input
and output for dust.
Only clean the input and/or output side in
case dust is clearly visible upon the
surfaces. Use an optical cloth. See service
manual chapter “Cleaning the lens”, page
292.
Note: if the lens was removed from the
projector, a manual “Lens Home & Return”
action must be executed to calibrate the
position of the lens in relation to the Lens
Holder. This way the references of the
existing 'lens files' remain valid. See user
guide of the Communicator software.
17 Lens Check the lens Zoom & Focus motors. Use the local keypad and the
Communicator software to Zoom and to
Focus.
18 Conver-
gence
Check convergence. See chapter “Convergence”, page 157.
19 Electronic
boards
Check the general condition of the
electronic boards in the Card Cage: Status
LED's, dust, connections, etc.
Blow out dust.
20 Security Check the Tamper Switch Activation Report
and Security Logs for security
infringements.
Report if intruded.
21 Cooling
Light
Source
Check the level of the Light Source cooling
reservoir. Refill if necessary.
See chapter “Check cooling liquid level &
cooling integrity”, page 92.
22 Color
calibration
Measure the color coordinates of the
projected image and calibrated if
necessary.
See user guide of the Communicator
software.
23 Documen-
tation
Check if the projector manuals are present
and up-to-date.
Download latest version from
www.barco.com.
24 Documen-
tation
Update projector service docket. List all maintenance actions and remarks.
Preventative maintenance actions
