R5906848 /04 DP2K SLP Series 83
Image 7-48
3. Remove the old phosphor wheel as illustrated.
Image 7-49
4. Carefully remove the protective covers from the new phosphor wheel. Use a T20 Torx screwdriver to loosen
the screws of the protective covers.
Laser Phosphor Light Source
