R5910123 /00 FL40 / FS40 Projectors
23
2.2 Service and maintenance
General
The FL40 / FS 40 projectors does not have any user serviceable parts.
All service tasks must only be carried out by the manufacturer, or a Barco authorized service personnel or
Barco technicians.
2.3 Power on / Standby button backlight
indications
Indicator
In addition to the LED indicator, the projector also displays status indications in the backlight of the Power /
Standby button.
The table below shows the details regarding this indications.
Operating Status
Indication Color / Behavior
On (active) Blue
Wait on Blue flashing
Standby (off) White
Wait White short flashing
Overheating Red flashing
Configure/upgrade White fast flashing
Standby ECO White heartbeat
Software Lockup Red
2.4 LCD Panel
2.4.1 LCD panel general
About
The LCD panel (See chapter 2.6, Local Keypad) is located on the right side of the projector, and has two
modes of indication; Mirror of the OSD, and Information display.
Toggle between the two indications by using the Menu button on the keypad, or on the remote control
1.
When mirroring the OSD, the LCD showing the menus and adjustment information.
2.
When in information mode, showing this Information regarding the status of the projector:
• Projector status
• Network address and status
• Active source
• Illumination Status
• Current firmware version
• Active functions (Enabled Functions).
• Display Info, including Transport delay
• Environment Info.
Use the navigation keys (arrows) to scroll the information menu.
When in information mode, press OK (confirm selection (✓)) to see notifications and warnings.
The LCD Display will fade out 15 seconds after the last key operation.
