R5910123 /00 FL40 / FS40 Projectors
78
Confirm with the ✔ button on the remote control, and the “Lens shift to center position?” pop up windows
shows up.
Move the highlighted rectangle to “OK”, and confirm with the ✔ key.
When EN68 lens is installed:
Due to restrictions in light output for the EN 68 lens, the mid position for this lens will not be the
mechanical mid position, but the mid position of the area where max light output is allowed.
Image 8-10
From the keypad
Press the Lens button on the keypad. A menu picture as shown below shows up.
Press the ✔ button for 3 seconds.
Image 8-11
8.2.4 Iris
General
Iris controls the contrast and focus depth of the image, and will also have an impact of the output light.
Decreasing the iris opening will increase contrast and image depth, at the same time as it decreases the
output light.
The FL40 / FS40 projectors has two irises; One in the lens, and one in the illumination path. They have both
mainly the same function, but with a small difference.
Installation menu
