R5910123 /00 FL40 / FS40 Projectors
96
Picture Left Picture RightBlend Zone
Image 8-52
How to adjust the level manually
1. In the main menu, select the Basic Black level menu
Image 8-53
2. Enable the ”Black level” and “Show lines” buttons.
Image 8-54
3. Move the cursor to the side where the overlapped area occurs. (Left/right/top/bottom.) For the left projector,
this will be the right side in the menu. Press enter, and adjust the value with the arrow keys. As mentioned
earlier, the value shall be slightly larger than the blend zone offset. A line that indicates the zone will also be
visible when “Show lines” is enabled. When the black level zone is optimal, press enter.
The value can also be entered by the numeric keys in the remote control.
4. Move the cursor to “Level”, press enter and adjust this level until the black level equals the level in the blend
zone.
This value can also be entered by the numeric keys on the remote control.
