LED-PRO • User’s Guide 89
4. Operation
Using the Expert Mode Menu
Following are descriptions of all menu functions:
• Baud — selects the baud rate. Values are: 1200, 2400, 9600, 19200, 38400.
• Parameters — select from the following values: N81, E71, O71, E72, O72.
• Handshaking — select from the following values: Off or On (CTS/RTS).
• Reset — enables you to restore the RS-232 settings to defaults: 38400, N81,
Handshake On.
Please note the following important points regarding diagnostic communications:
• After connecting your PC’s COM port to LED-PRO’s Diagnostic Port, you may
open a serial terminal session (using HyperTerminal, Procomm, etc.), and
configure the PC to match LED-PRO’s serial port settings as configured in the
Diagnostic RS-232 Menu.
• At this point, the LED-PRO command prompt (#) will be displayed at the terminal.
• Type "Help" to see a list of remote commands supported. In Appendix B, refer to
the “LED-PRO Remote Commands” section on page 128 for a complete list of
commands and descriptions.
bíÜÉêåÉí
On the System Menu, select the Ethernet function to display the Ethernet Menu, which
enables you to set Ethernet parameters.
Figure 4-72. Ethernet Menu (sample)
Following are descriptions of all menu functions:
• Mode — enables or disables Ethernet communications by turning the LED-PRO’s
Ethernet port on or off.
• DHCP — turns DHCP on or off.
~ When on, LED-PRO queries the DHCP server for a valid IP address. If
the LED-PRO finds a DHCP server and receives an IP address, the IP
address is shown. If a server is not found, the unit does not get an IP
address allotted to it.
~ When off, you can manually enter a static IP address (with valid subnet
mask and gateway) for Ethernet communication to properly function.
Consult with your network administrator for a valid IP address, subnet
mask and gateway.
ETHERNET
> Mode Off
DHCP Off
Set Static IP >>
IP 192.168.000.200
M 00:20:4A:84:9A:EE
Note
It takes several seconds for the unit to query the Ethernet port
and obtain the IP address. During this time the SEL button
will remain lit.
