Barco LED-PRO - Diagnostics Port; RS-232 Port

126 LED-PRO • User’s Guide
_K==oÉãçíÉ=`çåíêçä=mêçíçÅçä
Default Serial Parameters
aÉÑ~ìäí=pÉêá~ä=m~ê~ãÉíÉêë
Default serial communications parameters are provided for the following two ports:
• Diagnostics Port
• RS-232 Port
Please note:
• The system returns to these values after a factory reset.
• These settings can be changed using the menu system.
~ In Chapter 4, refer to the “Diagnostic RS232” section on page 88 for
instructions on changing Diagnostic Port settings.
~ In Chapter 4, refer to the “RS232” section on page 51 for instructions on
changing the RS-232 port settings.
aá~ÖåçëíáÅë=mçêí
Following are the default serial communications settings for the Diagnostics port, which is
used for diagnostics, software upgrades and serial commands (e.g., via HyperTerminal).
• Baud Rate = 38.4K baud
• Parity = NONE
• Stop Bit = 1
• Data Bit = 8
• Echo = ON
• Flow Control = NONE
opJOPO=mçêí
Following are the default serial communications settings for the RS-232 port, which is used
to communicate with the Director Toolset.
• Baud Rate = 19.2K baud
• Parity = NONE
• Stop Bit = 1
• Data Bit = 8
• Echo = ON
• Flow Control = NONE
