4. Operation
Using the Setup Menu
pÉíìé=jÉåì=aÉëÅêáéíáçå
The Setup Menu enables you to set up all LED-PRO input, output and system parameters.
If desired, all setup information can be stored in non-volatile memory (using the “Save
System State” function). Once saved, all settings will be automatically recalled each time
the unit is turned on.
The figure below illustrates the Setup Menu:
Figure 4-13. Setup Menu
Following are descriptions of each menu function:
• Setup Wizard
• Input Wizard
• Source Alignment — Analog
• Source Alignment — SDI
• Source Alignment — DVI
• Presets
• RS232
• Expert Mode
• Save System State
• Factory Reset
SETUP
> Setup Wizard >>
Input Wizard >>
Source Alignment >>
Presets >>
RS232 >>
Expert Mode >>
Save System State
Factory Reset
Note
The Source Alignment Menu changes depending upon the
format of the selected source — analog, SDI or DVI.
