120 LED-PRO • User’s Guide
^K==péÉÅáÑáÅ~íáçåë
Communications Specifications
`çããìåáÅ~íáçåë=péÉÅáÑáÅ~íáçåë=
The table below lists LED-PRO communications specifications.
* 115k Baud recommended for LED tile firmware upload only.
* 19.2k Baud recommended for normal operation, such as Director Toolset.
^ÖÉåÅó=péÉÅáÑáÅ~íáçåë=
The table below lists LED-PRO agency specifications.
Mounting 2 RU rack mount
Weight
17.5 lbs (7.93 kg)
Shipping Weight
20 lbs (9.07 kg)
Table A-4. LED-PRO Physical and Electrical Specifications (Continued)
Parameter Detail Specification
Table A-5. LED-PRO Communications Specifications
Parameter Detail Specification
Communications RS-232 DB-9 Female, DCE, 115k Baud *
Ethernet RJ-45, 10/100 Mbps Autosense
Table A-6. LED-PRO Agency Specifications
Parameter Detail Specification
Agency Specifications EMI/EMC EN55103-1 E4, EN55103-2, FCC Part 15 Subpart B Class A
Safety EN 60950 Class 1
