601–0445 /05 Loki40
4.1 Projector source and control connections
Overview
•
Making connections
• Connector specifications
• Control interfaces
4.1.1 Making connections
The source switching time is variable and could take few seconds..
Source signal connectivity
The connector panel at the back of the projector is used for all source connections.
Source signal connectivity on the projector is:
• 2x Dual Link DVI-I (DVI-D functionality)
• 2x DisplayPort 1.2
• 1x HDMI 2.0
• 1x HDBaseT
• 1x SDI input (initially designed for 3G-SDI input signals, 12G-SDI signals are now supported)
4.1.2 Connector specifications
Overview
•
DVI-I
• Display Port 1.2
• HDMI 2.0
• SDI
• HDBase T
4.1.2.1 DVI-I
Specifications
Parameter Value
Connector DVI-I female digital RGB
Signal characteristics DVI 1.0, Digital, TMDS
Max. cable length 25 m (24 AWG)
Max. pixel rate 330 MHz (dual link), 165 Mhz (single link)
Scan format Progressive
Max. input data resolution 1920x1200 60Hz (Single link), 2560x1600 60Hz
(Dual Link), 1920x1200 120 Hz (Dual Link),
1920x2400 @60Hz
Bit depth 8 bit
EDID Supported
HDCP Supported
