601–0445 /05 Loki 55
6.1 Contrast
About
Image / Contrast
Used to adjust the contrast ratio of the displayed image by applying gain to the red, green and blue signals.
Available range: 0.00 to 2.00
Default value: 1.00
Image 6-3: Contrast OSD menu
When inside this menu, it is possible to change to the other image adjustments (Brightness,
Saturation, Sharpness and Gamma) by using the up and down arrows on the remote control or
keypad.
6.2 Brightness
About
Image / Brightness
The brightness function is used to adjust the black level in the input picture. It adds or subtracts an offset, or
bias in to the red, green and blue signals.
Available range: –1.00 to 1.00
Default value: 0.00
Image 6-4: Brightness OSD menu
6.3 Saturation
About
Image / Saturation
Saturation levels impact on the white levels and the intensity of the color display; the higher the value, the
more vivid the color display will be.
Image menu
