601–0445 /05 Loki 79
If not possible to align the projector perpendicular to the screen, due to environment of other, see chapter
“Warp – 4 Corners adjustment”, page 87
Image 8-4
When EN 68 lens is installed in the projector, there are some limitations in the lens shift range, in
order to avoid damage to the lens.
This limitation will be identified as an reduction in the output light from the projector when the shift
position exceeds the defined range. The output light will then be reduced to 20% of max.
8.1.3 Shift to center
From remote control
This function adjust the lens position to the mechanical mid position.
Enter the menu Home/installation/Lens/Shift to center
Confirm with the ✔ button on the remote control, and the “Lens shift to center position?” pop up windows
shows up.
Move the highlighted rectangle to “OK”, and confirm with the ✔ key.
When EN68 lens is installed:
Due to restrictions in light output for the EN 68 lens, the mid position for this lens will not be the
mechanical mid position, but the mid position of the area where max light output is allowed.
Installation menu
