601–0445 /05 Loki 41
4.1.2.2 Display Port 1.2
Specifications
Parameter Value
Connector Standard Display port
Signal characteristics DP 1.2
Functionality Mandatory
Max. cable length 2 m (24 AWG) - RBR;
2 m (24 AWG) – HBR1, HBR2
Supported Link Rate RBR, HBR1, HBR2
Scan format Progressive
Max. input data resolution 2560x1600@120Hz WQXGA / 3840x2400 @60Hz
(4K ) Max
Bit depth 8, 10, 12 bit
EDID Supported
HDCP Supported
4.1.2.3 HDMI 2.0
Specifications
Regarding HDMI 2.0: The decryption protocol HDCP 2.2 are enabled and valid in this unit.
Parameter Value
Connector Standard HDMI
Signal characteristics Digital, TMDS
Max. cable length 2 m (24 AWG)
Max. pixel rate 594MHz
Max. input data resolution 3840x2160 @60Hz
Bit depth 8, 10, 12 bits
EDID Supported
HDCP Supported
Ethernet No
Audio return No
HDCP Supported
4.1.2.4 SDI
Specifications
Parameter 12G-SDI 3G-SDI
Standard SMPTE ST-2082-1 and ST-2082-10
standards
SMPTE 424M-2006 10bit level A
Connector Samtec BNC7T-J-P-HN-RA-BH1 1x) BNC 75 ohm type IEC 60169-8,
Amendment 2 1997, A
