Color Status
Off No monitor detected
Solid Red Monitor is detected, but the NGS-D200 is unable to read its EDID
Blinking
Red
Monitor is detected, but the NGS-D200 is unable to display the video because the output signal is
unsupported by the monitor
Solid Green Monitor is detected, and the video output is supported by the monitor
Blinking
Green
Decoder: Video is being decoded and is being displayed on the connected monitor
Table 2-4: Video Out Indicator Overview
2.6 Video Connection and Sync Specifications
l The NGS-D200 supports video input configured as either encoder or decoder.
