Appendix II: Making a Simple Connection Between an NGS-D200 Encoder and Decoder
Appendix II: Making a Simple Connection
Between an NGS-D200 Encoder and Decoder
This section outlines how to directly connect Standalone NGS-D200 encoders to decoders.
II.1 Prerequisites
l Both systems are operating in "Standalone" mode
II.2 Encoder Setup
1. Launch a web browser. In the address bar, enter the IPaddress/domain name of the NGS-D200 unit (e.g. 10.1.5.50)
2. Ensure the device is configured as an encoder and in "Standalone" mode. You will see this information on the top of
the Web UI.
l If the system is not, navigate to the Administration section of the page
o
If not operating in Standalone Mode:
n Under the Standalone Mode section, check the box.
n At the bottom of the page, click "Apply"
n Click "Save Settings"
o
If not an encoder:
n Under the System Control section, click "Encoder/Decoder." The system will reboot and
come up as an encoder
NOTE: After the system boots and you log back in, make sure to click "Save Settings"
to ensure the device will continue to come up as an encoder after any subsequent
reboots.
TIP: You can configure the encoder streaming parameters by configuring the
Connection Profile section of the page. For more information, see "Connection Profile"
on page 28
II.3 Decoder (client) Setup
1. Launch a web browser. In the address bar, enter the IPaddress/domain name of the other NGS-D200 unit
2. Ensure the device is configured as a decoder and in "Standalone" mode. You will see this information on the top of
the Web UI
l If the system is not, navigate to the Administration section of the page:
o
If not operating in Standalone Mode:
n Under the Standalone Mode section, check the box.
n At the bottom of the page, click "Apply"
n Click "Save Settings"
63 NGS-D200 User Guide
