Chapter 4: Installation and Connections
Chapter 4: Installation and Connections
The following topics are covered in this chapter:
4.1 Mounting the NGS-D200
13
4.2 Installation Diagram
13
4.3 Overview of Encoder/Decoder Dataflow
15
4.4 Connections for 3D/Stereoscopic Video
17
4.1 Mounting the NGS-D200
The NGS-D200 is designed to function as a desktop model. It is equipped with rubber feet to prevent scratching the surface
it is placed on. Additionally, two units can be mounted within a 1U rack space using the NGS-D200 rack mount kit (part
number C9826136 -
not included
).
4.2 Installation Diagram
The NGS-D200 should be installed according to the following diagram.
