Page #51 background image
Chapter 11: Video
Chapter 11: Video
The Video menu is used to get real-time information regarding the device or monitor EDID as well as to configure the device
video settings.
The following topics are covered in this chapter:
11.1 Video Diagnostics
43
11.2 Video Settings
43
11.1 Video Diagnostics
11.1.1 EDIDto Video Source
The EDIDto Video Source section displays the EDID being presented to the connected source.
11.1.2 Monitor EDID
The Monitor EDID section gives real-time information about the EDIDfrom the connected monitor.
11.2 Video Settings
11.2.1 Use Preferred Video Timings from Monitor
You can automatically synchronize the system EDIDwith that of the local monitor. The NGS-D200 will read the
EDIDinformation from the monitor and use this to automatically create a video look up table to capture the input video.
l Enable: check to enable
NOTE: When you have finished making changes, click "Apply" at the bottom of the page. Click "Save Settings" to
permanently save your changes to the device.
TIP: If you wish to connect a monitor to the NGS-D200 simply to get the EDID for image capture, then do the
following: from the Video section of the Web UI, you must first delete the “List of Preferred Timings in EDID to
Source then select to “Use Preferred Video Timings from Monitor,” click “Apply,” click “Save Settings” and then
reboot the system. Note that the “List of Preferred Timings in EDID to Source” section of the page will only appear
when the “Use Preferred Video Timings from Monitor” setting is disabled.
11.2.2 Video Input Type
You can set the EDIDvideo input for either digital or analog video.
l EDID Video Input: Select "Digital" or "Analog"
43 NGS-D200 User Guide
