NOTE: When you have finished making changes, click "Apply" at the bottom of the page. Click "Save Settings" to
permanently save your changes to the device.
11.2.3 Auto Detect Video Timings From DVI
NOTE: This option is used when DVIinput is used.
l Enable AutoLUT: check to enable
It makes the operation in DVImode easier. User does not need to create look up tables (LUTs)manually for input video
timing detection. NGS-D200 can automatically create a video LUT from input video timings.
When this option is enabled, other LUTs created in the system are ignored for video detection and the auto created
LUTtakes precedence.
If Use Preferred Video Timings from Monitor option is disabled, LUTs in the sytem can be used to announce specific
video timings over EDIDto source connected at input (not a common case)
NOTE: When you have finished making changes, click "Apply" at the bottom of the page. Click "Save Settings" to
permanently save your changes to the device.
11.2.4 Encoder Video Parameters
Once a connection is made, you can dynamically optimize the video quality by adjusting the video parameters.
Field Default Value Valid Entries
Sampling Phase 0 -16-15
Local Video Output Yes Yes, No
Fine Noise Elim 16 1-2048
Course Noise Film 10 1-256
Horiz Position 0 -135-375 (px)
Vert Position 0 -25-50 (px)
LUT Change Pump Curr Auto
Auto, 50, 100, 150, 250, 350,
500, 750, 1500 (µA)
Optimize Latency No Yes, No
I-Frame Interval 0 1-256 (ms)
Table 11-1: Default/Valid Encoder Video Parameters
l Sampling Phase: (Analog Video Only) The sampling phase is adjusted to minimize noise of the video source that is
result of the source's hardware (video card, cables, etc.) and video resolution. Ideally, this field should be set to a
level that minimizes bandwidth usage. You can check the bandwidth usage from the Display Connection
Information Page to find a sampling phase that works best for your deployment
