Chapter 10: Decoding Settings
Chapter 10: Decoding Settings
The following topics are covered in this chapter:
10.1 Decoding Settings
41
This menu is used to configure various decoder settings.
10.1 Decoding Settings
10.1.1 Display Parameters
Decoder Display Parameters is used to switch the decoder video mode from Local to Remote modes and is also used to
set the positioning of the video on the decoder and encoder sides.
Field Default Value Valid Entries
Video Source Remote Local, Remote
Override Monitor Monitor, None
Override Color Blue Blue, Yellow, Magenta, Cyan, Black, White, Gray, Red, Green
Horiz/Vert Position Location, Location Location, Offset
Horiz Location Left Left, Center, Right
Vert Location Top Top, Middle, Bottom
Horiz/Vert Offset 0, 0 0-horizontal (from left) or vertical (from top) pixels
Table 10-1: Default/Valid Decoder Display Parameters
l Video Source: Allows you to switch output video from Local, Remote modes
l Override: This menu allows you to define the scheme to render video on the decoder. You can choose to render
video in one of several ways:
o
Monitor: Video is rendered to fit the best supported resolution of the monitor
o
None: Video is rendered to match the resolution of the encoded video (at the encoder end)
l Override Color: If the scheme you select to render your video creates a negative space boarder around your video,
you can select what color the negative space will be
l Horz/Vert Position: Controls what scheme the system uses to offset the video
NOTE: When set to 'Location,' Horiz/Vert Location will be used to offset the video. When set to "Offset,"
Horiz/Vert Offset will be used to specify the offset (pixels).
l Horiz Location: When Horiz Position is set to 'Location,' specifies the horizontal location of your video
l Horiz Offset: When Horiz Position is set to 'Offset,' specifies the horizontal location of your video in relation to the
left edge of the display
l Vert Location: When Vert Position is set to 'Location,' specifies the vertical location of your video
41 NGS-D200 User Guide
