Barco NGS-D200 User Manual

Chapter 2: Product Overview
Function: NGS-D200 Lite NGS-D200 Pro NGS-D200 Pro 3D
Video
Resolution
Digital: 800 x 600
to 1920 x 1200
Max pixel clock
rate of 165 MHz
Digital: 800 x 600
to 2560 x 1600
Max pixel clock
rate of 330 MHz
Digital: 800 x 600 to
2560 x 1600
Max pixel clock rate
of 330 MHz
Analog: 800 x 600
to 1920 x 1200
Max pixel clock
rate of 170 MHz
Analog: 800 x 600
to 1920 x 1200
Max pixel clock
rate of 170 MHz
Analog: 800 x 600 to
1920 x 1200
Max pixel clock rate
of 170 MHz
Refresh rate Up to 120 Hz Up to 120 Hz Up to 120 Hz
Video Input
Stereo No No
TTL stereo out via
3.5 mm-to-RCA
cable
Connectors
Single-link DVI-I
(Analog and
Digital)
Dual-link DVI-I
(Analog and
Digital)
Dual-link DVI-I
(Analog and Digital)
Minimum/maximum
levels
Analog: 0.5V to
1.0V p-p
Analog: 0.5V to
1.0V p-p
Analog: 0.5V to 1.0V
p-p
Impedance Analog: 75 Ω Analog: 75 Ω Analog: 75 Ω
Maximum DC
offset
4.0V 4.0V 4.0V
Video Output
Stereo No No
TTL stereo out via
3.5 mm-to-RCA
cable
Connectors
Single-link DVI-D
(Digital)
Dual-link DVI-D
(Digital)
Dual-link DVI-D (
Digital)
Table 2-5: Video Specifications
2.7 Audio Connection Specifications
Audio Input
Type Stereo (two-channel), unbalanced
Connectors 3.5 mm stereo jack, 3.5 mm mic
Impedance 3 kΩ, DC coupled
Audio Output
Type Stereo (two-channel), unbalanced
Connectors 3.5 mm stereo jack, 3.5 mm headphone
Impedance 500 Ω, AC coupled
Table 2-6: Audio Connection Specifications
7 NGS-D200 User Guide

Barco NGS-D200 Specifications

General

Brand	Barco
Model	NGS-D200
Category	Media Converter
Language	English
