Chapter 4: Installation and Connections
Description
1 Power Adaptor
2 Primary LAN
3 Redundant LAN
4 Audio In (3.5 mm jack)
5 Audio Out (3.5 mm jack)
6 DVI-I In (DVI-D to DVI-D or VGAto DVI-A)
7 HOSTUSB (Type B)
8 3D
9 DVI-D Out
10-13 USB Slots for Keyboard/Mouse
14 Mic In
15 Headphone Out
16 SDCard
Table 4-1: Encoder/Decoder Configuration
4.3 Overview of Encoder/Decoder Dataflow
This section outlines the dataflow between the encoder and decoder.
After making a connection, the decoder side will see, hear, and control encoder-side source by default.
On the encoder side, the NGS-D200 loopback feature allows video, audio, and peripheral (USB) signals and data to pass
through for connection to a monitor, speakers and the source. This enables collaboration between the two sites as the user
at the encoder side can continue to operate their workstation as it is being shared with the decoder side.
NOTE: Video,audio and USBloopback are enabled by default on the encoder.
4.3.1 Typical Dataflow
The following diagrams outline the typical dataflow between an encoder and decoder.
15 NGS-D200 User Guide
